KENWOOD KA-8150

The Kenwood KA-8150 in mint condition is one of the highest quality audiophile amplifiers.Model: KA-8150 Type: Integrated amplifier Years of manufacture: 1977 - 1979 Made in: Japan Color: Bronze ("Gunmetal"), wooden cabinet optional Power consumption: 600 W max. Dimensions: 430 x 149 x 384 mm (WxHxD) Weight: 16 kg Original price approx.: 1298 DM Connections Number of inputs: 6 Phono 1: 2,5mV/50kOhm/ 85dB 250mV (RMS) max. Phono 2: 2,5mV/50kOhm/ 85dB Tuner: 150mV/50kOhm/110dB Aux: 150mV/50kOhm/110dB Tape A/B: 150mV/50kOhm/110dB Number of outputs: 3 Tape Rec.: 150mV/220Ohm Headphones: 6.3mm jack 2 speaker pairs Pre-Out: 1,0V/470Ohm Technical Data Continuous power (at distortion factor) 8 Ohm: 75W + 75W 4 Ohm: 90W + 90W Dynamic power 8 Ohm: 4 Ohm: 330W Total harmonic distortion: 0.03% at rated power into 8 ohms. 0.01% at 1W into 4 Ohm Attenuation factor: 50 at 8 Ohm Frequency response: 5 - 50000 Hz Phono: RIAA standard +/- 0.2dB Aux/Tape: 7 - 50000 Hz +0dB / -1dB Signal to noise ratio: 115dB Tone control(switchable): Bass: yes (150 or 400 Hz switchable) +/- 7.5dB. treble: yes (3 or 6 kHz switchable) +/- 7,5dB Loudness: yes (6 levels) 50Hz: +3dB/+6dB/+9dB 100Hz: +3dB/+6dB/+9dB High Filter: yes - 8kHz/12dB / octave Low Filter: yes - 40Hz/12dB / octave Subsonic Filter: yes - 18Hz/6dB / octave Mute: no, but a gain control switch -10dB/ 0 / +10dB Direct/Line-Straight: yes - at the turnover switches of the tone controls Special Features Pre- and power amplifier can be separated via jumper plugs on the rear panel Double power supply, separate for both channel
