E bike C 29

Product details Component geometry Basic geometry Electronic Spec Motor 48V 750W motor Torque 65 Nm Battery 48V 15Ah battery Battery Charger 54.6V 2A charger Charging Time 6–8 hours Display 2.4" HD display, Bluetooth-enabled for Duotts App Max Range Up to 100 km in assist mode (actual performance varies with temperature, terrain, rider weight, etc.) Top Speed 25 km/h Max Climbing Angle 30° Components Spec Frame Aluminium alloy frame Handlebar Aluminium alloy handlebar, 68 cm Crank Aluminium alloy crank, 170 mm Transmission System Shimano Tourney 3×7-speed derailleur system Fork Single-crown aluminium suspension fork, 100 mm travel, non-adjustable, with lockout Rear Shock Not specified Front Brake Disc brake, 160 mm rotor Rear Brake Disc brake, 160 mm rotor Front Wheel Chaoyang 29" x 2.125" tyre, 30 TPI, with inner tube Rear Wheel Chaoyang 29" x 2.125" tyre, 30 TPI, with inner tube Headlight 300 LUX headlight, manually operated Taillight Not specified Pedal Aluminium alloy pedals Mudguard Plastic mudguards Rear Rack Steel rear rack, max load 25 kg General Spec Bike Weight 26.5 kg Certification CE (EN15194) certified Product Size 1860*1080*680 mm Pedal Assist System Speed sensor Pedal Assist Level 0-5 levels Recommended Rider Height Suitable for riders from 170 cm to 200 cm Max Load Capacity 150 kg Ingress Protection Rating IPX4 Operating Temperature -10°C to 40°C Package Include Charger, user manual, 16-in-1 tool, thumb throttle, pedals, quick-release axle, motor axle protectors, air pump, phone bag Recommended Rider Height 170–200 cm Max Load Capacity 150 kg Bicycle Weight 26.5kg A. Seat Height (Maximum) 103cm B. Seat Height (Minimum) 85cm C. Rear Rack Height 79cm D. Wheelbase 113cm E. Rear Chainstay 47cm F. Seat Tube 42cm G. Top Tube 54cm H. Down Tube 73cm I. Front Fork 63cm J. Wheel Height 72cm K. Bike Height 108cm L. Bike Length 186cm Influencer Assessment Learn more about the excellent performance of Duotts commuter ebike C29 h
