€970

Description

MAXIMUM USE OF ENERGY Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm. Combustion of fuel particles thanks to deflector, which extends the exhaust gas path. Increased efficiency of the insert through manual control of chimney draft by using the built-in damper. Manual control over the combustion process carried out by ash tray regulator. SAFETY AT THE HIGHEST LEVEL Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C. Decorative fence helps to maintain the tidiness and protects against falling out of wood. CONVENIENT TO USE The cold handle system which limits the risk of burns due to the possibility of removing it while burning. Ash drawer / ashtray, where the remains of burnt wood are gathered and grate for easy ash removal. Reduced soot deposition through a system of pure glass (air curtain) Version Front facing Nominal power (kW)15 Heating power range (kW)7-18 Thermal Efficiency (%)80.2 Flue gas temperature (oC)288 Max billet length (cm)50 Minimum required active area of inlet grilles (cm2)≥800 Minimum required active field of outlet grilles (cm2)≥1000 diameter of the flue gas outlet200 COLOUR Black CLOSING No Materials Cast iron Door opening /Left Energy class A EEI 106 Seasonal Energy Efficiency (%) 70 Heat output for space heating (kW) 15 CO emission (at 13% O2) ≤ given in % 0.111 CO emission (mg/m3)1388 Pollen emission (mg/m3)14 NOx emission (mg/m3) 104 OGC emission (mg/m3) 95 Flue gas mass flow (g/s)11.8 Certifications / Compliance Certificates Ecodesign Width (cm)65.2 Height (cm) 81 Depth (cm)44.2 Weight (kg)150
