Strautmann Magnon 11-430 Short-Cut Forage Wagon

Shortest cutting length on the market at 22mm theoretical cutting length Loading capacity without extension 40.5m³ Minimum wear and optimum adaptation to ground due to the innovative Flex-Load pick-up with plastic tines The continuous flow unit ensures excellent performance with little power required Hydraulic tandem chassis (BPW) with electro-hydraulic active steering Axle load rating: 20 t Brake size: 410 × 180 mm Wheels: 4 × 710/50 R26.5, 170D, 10-hole Tyres: BKT FL 630 Ultra Combined braking system: air brakes with ALB and integrated hydraulic brakes Suspension system for hydraulic tandem chassis Drawbar & Coupling: Low drawbar design Ball hitch with 4 t coupling load Crash protection for drawbar with active steering Hydraulics & Control: Hydraulic clutch with load-sensing connection (sizes 2 and 4) ISOBUS Basic operation (required for forced steering) ISOBUS terminal, 5-inch display Superstructure & Driveline: Superstructure for Magnon CFS 11-430 Sidewall extension: 90 mm Overall height exceeds 4.0 m with 30.5" wheels PTO shaft: single-sided wide-angle, Z = 6, 1 3/8" Pick-up & Safety Equipment: 2.25metres picking-up width Sensing roller behind pick-up Side marking lights Front marker lights Outline marker lights Rotating beacon light Lighting: 2 × LED working lights 1 left, 1 right, mounted front under the platform All sales completed through authorised Strautmann dealers (ROI/NI) Martin (Leinster/Connacht/Ulster Sales): +353 (0) 87 9061920 JP (Munster Sales): +353 (0) 87 1248403
